853D 5A-II Soldering Rework Station with Hot Air Heat Gun and Soldering Iron
Inquiry

853D 5A-II Soldering Rework Station with Hot Air Heat Gun and Soldering Iron

Parameters

Model: YIHUA 853D 5A-II
Power Consumption: 970W
Measurement: L250xW190xH137mm ±5mm
Working Temperature: 0~50°C
Storage Temperature: -20-80°C

Hot Air Reworks

Power: 700W
Airflow type brushless fan gentle wind
Airflow: ≤120L/min
Temperature range: 100°C-480°C
Temperature Stability: ±1°C

Soldering Iron

Power: 32W (max: 120W)
Temperature Range: 200°C-480°C
Temperature Stability: ±1°C
Tip to Ground Voltage: < 2mV
Tip to Ground Impedance: < 2 ohm
Iron heater material: high-power heater
Iron Handle Color: blue

DC Power Supply

Output Power: 150W
USB Output Power: 10W
Output Voltage: DC 0~30V
Output Current: 0~5 adjustable
Load Stability: < 0.01±2mv
Temperature Coefficient: < 300ppm/°C
Ripple dB: < 1mvrms (virtual value)

Features
  • Equipped with soldering iron, hot air gun, power supply, and 5V 2A USB interface for charging during repair.
  • Designed with PID program-controlled temperature control technology for more stable working temperature.
  • Lightweight for easy transportation;
  • This soldering station is also equipped with the following user-friendly functions: 1) Digital temperature correction function for precisely controlling working temperature;
    2) Celsius/Fahrenheit display temperature conversion function;
    3) Soldering iron 0-99 minutes sleep function for saving energy;
    4) Hot air fan malfunction protection for safe operation;
    5) The power supply is designed with an over-temperature protection function.
